Product Description
Units are used and may show signs of normal usage such as scratches, scuffs, and dings. Items were acquired from working environment at SD State University (marked SDSU) and reported as fully operational, however some came with broken or missing lamps. Units power up and function as expected without lamps but no further testing was done so are listed AS IS, PARTS ONLY.Â
Sharp XG-C435X Specs
POWER DEVICE
Type: power supply
Nominal Voltage: AC 120/230 V
Frequency Required: 50/60 Hz
Power Consumption Operational: 360 Watt
CHASSIS
Built-in Devices: speaker
INTERFACE PROVIDED
Qty: 1, 2
Connector Type: 15 pin HD D-Sub (HD-15)   24+1 pin digital DVI   4 pin USB Type B    4 pin mini-DIN   9 pin mini-DIN   RCA, RJ-45   mini-phone 3.5 mm   mini-phone stereo 3.5 mm
DISPLAY
Image Brightness: 4000 ANSI lumens
Image Contrast Ratio: 550:1
Image Size: 39.8 in - 500 in
Projection Distance: 4.7 ft - 70 ft
Max Sync Rate (V x H): 85 Hz x 70 kHz
POWER
Power Consumption Stand by / Sleep: 6 Watt
VIDEO OUTPUT
Analog Video Signal: RGB, component video
VIDEO INPUT
Digital Video Standard; Digital Visual Interface (DVI)
Video Modes: 1035i, 1080i, 480i, 480p, 540p, 576i, 576p, 720p
Analog Video Format: NTSC, PAL, SECAM
Analog Video Signal: RGB, S-Video, component video, composite video
Video Interfaces: DVI, S-Video   VGA, composite video
TV System: NTSCÂ Â Â SECAMÂ Â Â PAL
ENVIRONMENTAL PARAMETERS
Sound Emission (Economic Mode): 31 dB
HEADER
Brand: Sharp
Product Line: Sharp
Model: XG-C435X
Compatibility; Mac   PC
OPERATION
Lamp Type: NSH 275 Watt
Lamp Life Cycle: Up to 2000 hour(s) - normal mode
Up to 3000 hour(s) - economic mode
Nominal Voltage: AC 120/230 V (50/60 Hz)
PROJECTOR
Class; digital projector
Recommended Use; presentation and multimedia
Type: LCD projector
Portability; non-portable
Min Image Size: 39.8 in
Max Image Size; 500 in
Native Resolution; 1024 x 768
Max Resolution (Resized):Â 1400 x 1050
Display Resolution Abbreviation: XGA
Max V-Sync Rate: 85 Hz
Max H-Sync Rate: 70 KHz
Video Bandwidth: 108 MHz
Native Aspect Ratio: 4:3
Brightness:Â 4000 ANSI lumens
Brightness (Reduced): 3200 ANSI lumens
Contrast Ratio: 550:1
Min Screen Distance: 4.7 ft
Max Screen Distance: 70 ft
Throw Ratio: 1.8 - 2.1:1
Uniformity: 90 %
Projector Features: Eco-Mode technology, integrated de-interlacer (progressive scan)
AUDIO OUTPUT
Type: speaker(s)
Sound Output Mode: mono
Form Factor: integrated
Output Power / Channel: 2 Watt
PROJECTOR LENS SYSTEM
Lens: standard lens
Focus Type: manual
Lens Aperture: f/1.7-1.9
Zoom Type: manual
Zoom Factor: 1.2x
DIMENSIONS & WEIGHT
Width: 12.8 in
Depth: 11 in
Height: 4 in
Weight: 10.8 lbs
AUDIO OUTPUT DETAILS
Speaker Type: mixed channel
Speakers Qty: 1
CABLE DETAILS
Type; VGA cable, serial adapter
