Product Description
Custom built Visa Lighting Southridge Style Outdoor Luminaries w/ OW1420 light pattern.Â
OW1420-VAR54286-1-1PH100
(MTAP)-NB5022
Dimensions:
14" x 14" x 4.75"
Pin Spacing: 12" x 5"
Recessed Depth: 5.25"
100W ED17, Med Base, Pulse Start MH
ƒ Fabricated metal front shield (OW1400, OW1402, OW1420, OW1422)
ƒ Cast aluminum, fully gasketed and sealed source chamber
with clear tempered glass enclosure
ƒ Oven cured no VOC acrylic powder coat
ƒ Selection of front shield styles
ƒ Front shield features snap lock for easy tool-less relamping
ƒ HID or incandescent source
ƒ Clear source required for sharp pattern effect
ƒ Remote mounted HID ballast with long distance ignitor standard, 50' maximum ballast
to source distance, PH70(347V) is 20' maximum, PH100(347V) is 15' maximum
ƒ Recessed mounted housing for shallower extension from wall
ƒ ETL listed to UL standards (US and Canada) for wet location mounting 4' above grade
